USB 3.0 MIPI Camera Board Frame Grabber Board 100K-1M IC Rate ESD Protection

USB 3.0 MIPI Camera Board

USB 3.0 Frame Grabber Board

ESD Protection MIPI Board

Place of Origin:

Shenzhen, China

Brand Name:

Dothinkey

Certification:

Model Number:

CP41

Request A Quote

USB 3.0 MIPI Camera Board Frame Grabber Board 100K-1M IC Rate ESD Protection

Product Details

OS Characteristics:

Support 4X36 Channels OS Test

MIPI Data Channel:

4CH D-PHY

Sensor Clock:

6 ~ 99MHz ±0.01MHz

DPS Characteristics:

Supports 16 Adjustable Power Supplies

Power Supply:

DC12V/8A

Analog Measurement Inputs:

Measurement Range: -2 ~ 5V, Accuracy: ±10mV

I²C Rate:

100K-1M

LC Characterization:

Supports 4X20 LC Tests

Highlight:

USB 3.0 MIPI Camera Board

USB 3.0 Frame Grabber Board

ESD Protection MIPI Board

Payment & Shipping Terms

Minimum Order Quantity

Price

USD1200-USD5000

Packaging Details

Carton Packaging

Delivery Time

5-8 Working Days

Payment Terms

T/T

Supply Ability

Stock Available

Related Products

86-755-6114-6178

Contact Now

Product Description

USB 3.0 MIPI Frame Grabber Board 100K-1M IC Rate ESD Protection for Automotive Applications

Featutes:

1. CSI-2 compliant quad-lane MIPI D-PHY receiver
2. 16-channel programmable power supply unit (4×4 topology)
3. Precision current measurement system (1nA - 2A dynamic range)
4. Distributed OS test network with 144 test nodes
5. Isolated analog input channel (±10V, 100kS/s)
6. Power integrity analysis with PSRR/PARD measurements
7. LP mode voltage transient capture (1mV resolution)
8. Smart cable compensation via Kelvin sensing
9. Automated sensor characterization toolkit

Schematic:

USB 3.0 MIPI Camera Board Frame Grabber Board 100K-1M IC Rate ESD Protection 0

Dimention:

USB 3.0 MIPI Camera Board Frame Grabber Board 100K-1M IC Rate ESD Protection 1

CP41 DPS Maximum Load Capacity:

Channel	DPS Output Voltage	Maximum Output Current	Note
AVDD	0.5V-5V	0.5A	The sum of the individual module channel current values must not exceed 1A. Description: 1) A single module channel has 4 DPS power supplies for user configuration; 2) There are 4X4 DPS power supplies for four module channels for user configuration; 3) Please do not exceed the technical specifications provided in this table when using DPS, otherwise it will damage the product or affect the testing accuracy. Otherwise, the product will be damaged or the testing accuracy will be affected.
DVDD	0.5V-3.3V	0.8A
DOVDD	0.5V-5V	0.5A
VPP2	0.5V-5V	0.5A
