5Gbps USB3 Frame Grabber Single Camera Image Frame Grabber

5Gbps USB3 Frame Grabber

Single Camera USB3 Frame Grabber

Single Camera Image Frame Grabber

Brand Name:

Dothinkey

Model Number:

FM101

Request A Quote

5Gbps USB3 Frame Grabber Single Camera Image Frame Grabber

Product Details

Input Voltage:

110V/AC ~ 220V/AC 50Hz/60Hz

Output Power:

DC 24V/2.5A

Power Supply:

DC 24V/2.5A

Module Type:

MAXIM/TI Serializer Module

Number Of Module Channels(MAX):

Single Channel

Module Power Supply Method:

POC Power Supply

PC Communication Interface:

5Gbps USB3.0 Interface

Module Interface:

1、Standard FAKRA Coaxial Single-ended Interface；2、Reserve STP Interface Position

External Interface ESD Protection:

Human Body Model (HBM) ≥ ±4000V Machine Model (MM) ≥ ±200V

2 Programmable Power:

2 Independent Power,0.8-18V Programmable,please Refer To The Following Table

Supported Functions:

Single Camera Application,supporting FAKRA Coaxial Single-ended Or STP Differential Interface Automotive Module Testing Applications

Highlight:

5Gbps USB3 Frame Grabber

Single Camera USB3 Frame Grabber

Single Camera Image Frame Grabber

Payment & Shipping Terms

Price

USD1200-USD5000
