Cell Phone Camera Module Image Grabber National Instruments Frame Grabber

Cell Phone Camera Module Image Grabber National Instruments Frame Grabber

Phone Camera Module Image Grabber

Camera Module Image Grabber

National Instruments Frame Grabber

Place of Origin:

Shenzhen, China

Brand Name:

Dothinkey

Model Number:

GSL20

Contact Us
Request A Quote
Cell Phone Camera Module Image Grabber National Instruments Frame Grabber
Product Details
Highlight:

Phone Camera Module Image Grabber

,

Camera Module Image Grabber

,

National Instruments Frame Grabber

Payment & Shipping Terms
Minimum Order Quantity
1
Price
USD1200-USD5000
Delivery Time
Negotiable
Payment Terms
T/T
Related Products
Contact Us
86-755-6114-6178
Contact Now
Product Description

Equipment for testing cell phone camera modules



Dothinkey Launches Image Grabber for Testing Mobile Phone Camera Modules



Cell Phone Camera Module Image Grabber National Instruments Frame Grabber 0



The Image Grabber of this GSL20 has 2 sets of GND for each image sensor, in the case of not dividing the GND of the image sensor, DGND and AGND can be connected together with the GND of the image sensor; if the demand is to divide the GND of the image sensor, the digital ground of the image sensor is connected with DGND, and the analog ground of the image sensor or other GNDs are connected with AGND.



The internal pull-up resistor of GSL20's I2C pin is divided into 4.7K, 1.5K and 560R to connect to DOVDD, which can be configured into pull-up resistors with different values according to the actual application through the corresponding function, and the default is 1.5K pull-up resistor.
