Industrial Grade USB Frame Grabber MIPI Capture Card D PHY And 8X39 OS Support

USB MIPI Frame Grabber Industrial Grade D PHY and 8X39 OS Support

Featutes:

1. Dual MIPI D/C-PHY Imaging Interface
   Dual-channel image acquisition compliant with MIPI D-PHY 1.2 and C-PHY 1.1 protocols, supporting data rates up to 6 Gbps per lane for high-resolution sensors.
2. 2×5 Configurable Power Rails
   10 independent programmable outputs (0.8V–3.3V, ±1% accuracy), enabling simultaneous multi-sensor power optimization (e.g., 2.2V core + 1.8V I/O).
3. Multi-Range Current Sensing
   Precision measurement from 100 mA to 10 nA (0.5% FS accuracy) with auto-ranging for dynamic power analysis.
4. 66-Channel OS Test Matrix
   Open/short detection across 66 signal paths (contact resistance <1 Ω) via programmable load switching.
5. Dynamic Product ID Programming
   On-board EEPROM supports 128-bit unique identifier configuration for IoT/Industry 4.0 traceability.
6. Analog Measurement Interface
   16-bit ADC with ±10V input range for external voltage/current monitoring (e.g., temperature, ambient noise).
7. Real-Time Rail Monitoring
   Continuous voltage feedback (50 kHz sampling, ±0.5% accuracy) with overvoltage/undervoltage alerts.
8. 4-Wire Kelvin Power Delivery
   Remote sensing compensation for <10 mV voltage drop across 2-meter cables (4-wire configuration).

Schematic:

Power connector description:

CP20 Product Specifications:
